Binocular Balancing

Binocular Balancing

For Binocular px’s with 6/12 or better – WHY?! Because if the “fog” or “blur” gets too heavy the fogged eye will not serve as a binocular cue/fusion lock/accommodation lock, and the whole technique breaks down. Binocular vision is not maintained.

  • It’s a technique to ensure the accommodation of the eyes is equal & zero – we aim to equalise the accommodation between both eyes at zero.
  • Both eyes will always accommodate by the same amount binocularly (when working together), even if they don’t under monocular conditions.
  • If the right & left eyes are not “balanced” (have the same accommodation), the eyes will accommodate by the least amount possible to produce a clear retinal image in one eye – the other eye may have a slightly blurred image & eye strain may result.
  • g. – Px aged 20, Rx is actually:
  • RE: +1.00DS 6/5      LE: +1.00DS  6/5

But refractionist gives:

RE: +1.00 DS             LE: +0.50DS

  • Monocular VA would be:

RE: 6/6 no accommodation in either eye

LE: 6/5 0.50D accommodation in both eyes

  • Binocular VA would be:

no accommodation in either eye

RE: 6/5         LE: 6/9

  • This may tend to alternate between eyes & vary the accommodation or Px tries to use one eye for near – results in poor quality binocular vision & discomfort.
  • Binocular balancing is necessary following right & left monocular refractions. (after F&B /cross cyl).
  • Assume equal/similar VA
  • Several techniques include:
  • Turville Infinity Balance
  • Humphriss Immediate Contrast
  • Polarised Duochrome
  • Prism Dissociation
  • Turville Infinity Balance (TIB):
  • F & L targets separated by a septum (see only one letter with each eye)
  • Try to achieve equality by simultaneous comparison
  • RE can see L but not F, LE can see F but not L (these letters are directly in front of each eye)
  • Set up by covering LE (with cover) & moving septum until F is covered, then occlude RE & check that now L is covered. (Then remove cover from both eyes).
  • Both eyes see rest of chart & room
  • If correction is not balanced F & L cannot be clear at the same time, even if vision is 6/5 R&L monocularly.
  • Ask Px if F & L are equally clear – if equal that’s the end of the procedure.
  • If there is a difference,
  • Add +0.25DS to worse eye, continue until VA starts to reduce (still looking at L & F)
  • If VA reduces with first +0.25DS add +0.25DS to better eye until VA starts to reduce
  • If VA reduces with first +0.25DS on better eye, add -0.25DS to worse continue until VA stops improving.
  • g. Px’s true correction: RE: +2.00DS       LE: +2.00DS

With present Rx in place, L (RE) is clearer than F (LE). There are three ways you can get it wrong to give this result:

  • L>F because left eye is under-plussed

e.g. you have     RE: +2.00DS       LE: +1.50

  • each eye is 6/5 monocularly but right eye controls accommodation. Left VA binocularly is ~6/9 (0.50DS blur). (so if you’re missing 0.50DS for accom. off left eye, VA reduces by about 2 lines because 1/0.50 = 2?)
  • So you add +0.25DS to left eye, left VA increases to ~6/6 so F becomes more similar to L. Add a further +0.25DS, left VA increases to ~6/5, F & L become equally clear
  • (N.B. this is the only occasion where adding small amounts of plus will improve a young person’s VA, normally in young Px plus makes VA stay same or get worse).
  • If adding first +0.25DS makes F even worse, then cause is not as described above.
  • L>F because RE is under plussed but controlling accommodation for both eyes

e.g. you have     RE: +1.50DS       LE: +2.00DS

  • Binocularly, because RE is controlling accommodation, both eyes accommodate by +0.50DS making RE 6/5. The “correct” LE also accommodates by 0.50DS reducing its acuity to ~6/9 (what makes L>F)
  • Add +0.25DS to better eye (RE) & ask what effect it has on right VA, then left VA. If 2) is correct reason right VA will not be affected, left VA will improve. (RE (6/5) relaxes accommodation by 0.25DS (still 6/5), also relaxes LE’s accommodation by 0.25DS, left VA increases from ~6/9 to ~6/6 & F becomes more similar to L)
  • Add further +0.25DS to RE for as long as right VA does not reduce & left VA continues to improve. (RE relaxes accommodation by another 0.25 (still 6/5), also relaxes LE’s accommodation by 0.25DS. Left VA increases from ~6/6 to ~6/5 & F becomes equal to L
  • (Adding further +0.25DS would blur RE from 6/5 to 6/6. Left eye would remain 6/5 – F becomes worse than L)
  • If adding plus to better eye decreases better eye’s VA then 2) cannot be correct.
  • L>F because LE is under-minused

e.g. you have     RE: +2.00DS       LE: +2.50DS

  • Add -0.25DS to worse eye (LE). Left VA increases from ~6/9 to ~6/6
  • Add further -0.25DS to LE. Left VA increases to 6/5 & F = L
  • Add further -0.25DS to LE. Either LE blurs or LE starts to accommodate & makes RE go blurred & F ≠ L
  • 3) should not happen – LE was never at max VA
  • If none of the above work, check the cylinder &/or use the pinhole
  • B. the idea is NOT to make F = L by blurring the better eye to the level of the poorer eye
  • We monitor the level of accommodation by noting the way VA of each eye changes with lenses. VA is fixed, determined by health of the eye.
  • If VA.s are slightly different it is still essential to balance the accommodation – we can still do the TIB.

Rather than seeing F = L as objective, we ensure that each eye is achieving its optimum VA with minimum accommodation (i.e. so that after adding plus to either eye makes the VA worse)

  • Patients NOT suitable for TIB:
  • Strabismic patients (squints)
  • Large difference in VA between the eyes
  • Very unstable phoria (poorly compensated heterophoria) making the F & L move around excessively
Read More


Colonoscopy is an objective technique (most common method)

(so up makes lens stronger)

  • The vergence of the illumination affects the speed of the reflex (rets have slide to vary vergence)
  • Hence light can be convergent, divergent or parallel
  • Change is vergence does not affect value of neutral but does affect direction & speed of reflex
  • Varying vergence can be useful:
    • To speed up a slow reflex when there is a large refractive error by making the beam parallel. Remember the case of The Skip hire Glasgow company.
    • To slow down a fast reflex to find neutral more accurately by making the beam divergent
  • The smaller the sight hole the more closely defined neutral is & the more accurate the retinoscope. But a small sight hole makes it harder to see a dim, out of focus reflex
  • Astigmatism – different speed reflexes in different meridians, can only occur when one meridian is close to neutral
  • Should end up with neutral in all meridians
  • Using minus cyls are more forgiving so use those. If see two with movements initially, correct slowest, thickest & dullest with a plus lens (sphere) causing other meridian to become an against movement, therefore needing a minus cyl to neutralise it
  • If see against movements both meridians initially, correct fastest, thinnest & brightest to still leave the other as an against movement
  • Finally if see a with movement in one meridian & an against in other, neutralise with movement first
  • Before starting make sure there is an against movement in the other eye to make sure they are not accommodating – the fixing eye controls the accommodation of both
  • Retinoscopy – what can it tell you about your Px?
  • Refractive error
  • Media changes – cornea, lens, vitreous
  • Cataract vitreous opacities
  • Retinal detachment
  • Active accommodation
  • Ability to fixate
  • Independent of subjective availability of Px
  • Still requires some Px cooperation
  • Need to control accommodation & fixation
  • Results used:
  • As the starting point for subjective tests
  • As the Rx if subjective refraction is unreliable e.g. infants
  • In some Px’s this might be the only way of assessing refractive error
  • Stroke victims
  • Cerebral palsy
  • Downs syndrome
  • Young children
  • Uncooperative patients
  • Two types of ret are available – a spot ret & a streak ret
  • The ret contains halogen bulb, rheostat to control brightness & oblique mirror with central aperture – these can reduce brightness of reflex
  • Ret technique:
  • A cone of light is shone into the eye
  • Some of the light passes through the pupil & is reflected off the Px’s retina
  • Remainder of light falls on ocular adnexa forming a facial light patch
  • Practitioner observes movement of light reflected from Px’s retina, called reflex
  • When performing ret movement of retinal reflex is compared to movement of facial light patch
  • Three movement options:
    • No movement (parallel beam – pupil is ‘filled’ with light) – emmetropia
    • Against movement (convergent beam) – myopia
    • With movement (divergent beam) – hypermetropia
  • Observer interprets light reflex seen in Px’s pupil
  • Ret places patch of light on Px’s retina – acts as a ‘secondary source’ & light from this source is refracted by Px’s eye
  • Ret method:
  • Define working distance
  • Dim the lights – NOT off
  • Ask Px to look at green on duochrome (distant target) – distant as correcting distance vision so don’t want them to be accommodating
  • If Px has a strabismus, occlude good eye while ret-ing strabismic eye
  • Use RIGHT EYE & RIGHT HAND to test Px’s RIGHT EYE, vice versa
  • Move beam side to side & note reflex movement
  • Ret technique:
  • Endpoint = neutralisation of the eye (neutral = no movement of reflex)
  • Split reflex – moves in both directions (scissor movement), only apparent when neutral so not a problem
